Color Steel Tile Solar Rooftop Mounting System Solution

Overview

Addressing the installation needs of large-area color steel tile roofs in industrial plants, warehouses, and other settings, we utilize a direct connection technology between clamps and pressure blocks to achieve rapid deployment without requiring rails or penetrations. The solar panel components are directly fixed to the clamps via side/middle pressure blocks, and the clamps tightly grip the corners/upright lock edges of the color steel tiles at their peaks or valleys, without damaging the roof structure. With a core focus on “rail-free direct connection, minimalist structure, strong load resistance, and economic advantage”, our product provides a cost-effective, robust, and reliable system solution for industrial and commercial rooftop photovoltaic projects.

Material and Craftsmanship: The main body of the fixture is made of AL6005-T5 aluminum alloy, paired with 304 stainless steel bolts, providing strong resistance to salt spray corrosion.

Trackless direct connection design: Abandoning traditional tracks, the clamps are directly fixed to the wave crests/troughs of color steel tiles, coupled with the pressing block locking components, reducing material usage by 30% and significantly lowering the overall system budget.

Full tile type compatibility: covers mainstream color steel tile types such as angle-type and straight-edge-locked type.

Lossless installation: The fixture is tightly engaged with the color steel tile through anti-slip teeth, eliminating the need for drilling or welding, thus avoiding the risk of roof leakage and adapting to new construction or renovation projects. Photovoltaic bracket for color steel tile roof
Adopting an “all-aluminum alloy” solution, crafted from high-quality primary aluminum material, the system is lightweight and highly pre-assembled, effectively saving manpower and time costs on project construction sites;
The color steel tile photovoltaic bracket has strong tensile pull resistance and is easy to install, ensuring the rapid delivery of the project;
We provide specialized customized designs for different types of color steel tiles, achieving a perfect integration between the tiles and photovoltaic supports to meet various installation needs of our customers.
1. Convenient installation: It is compatible with the special structure of color steel tiles, eliminating the need for drilling and damaging the roof. It adopts clamps for quick installation, resulting in a short construction period without affecting the normal use of the roof.
2. Load-friendly: The bracket structure is lightweight, with a low self-weight, and imposes minimal additional load on the color steel tile roof, effectively reducing the load pressure on the roof and ensuring the safety of the roof.
3. Excellent waterproofing: The installation process does not damage the waterproof layer of the color steel tiles, and some of the brackets feature waterproof optimization design, which can further enhance the waterproof performance of the roof and reduce the risk of water leakage.
